Starlink Specifications
Package Weight 2.89 kg (6.37 lbs)
Package Dimensions 430 x 334 x 79 mm (16.92 x 13.14 x 3.11 in)
Antenna Electronic Phased Array
Field of View 110 °
Orientation Software Assisted Manual Orienting
Weight 1.10 kg (2.43 lb)
1.16 kg (2.56 lb) with Kickstand
1.53 kg (3.37 lb) with Kickstand & 15 m Cable
Environmental Rating IP67 Type 4 with DC Power Cable and Starlink Plug/Cable installed
Operating Temperature -30°C to 50°C (-22°F to 122°F)
Wind Speed Operational: 96 kph+ (60 mph+)
Snow Melt Capability Up to 25mm / hour (1 in / hour)
Power Consumption Average: 25-40W
Input Rating 12-48V 60W (12v short Starlink cable coming soon in Shop)
USB PD Requirement 100W, 20V/5A Minimum (with Starlink USB-C to Barrel Jack Cable Accessory)
Wi-Fi Technology 802.11a/b/g/n/ac
Generation WiFi 5
Radio Dual Band 3 x 3 MU-MIMO
Ethernet Ports One (1) Latching Ethernet LAN port with Starlink Plug
Coverage Up to 112 m² (1,200 ft²)
Security WPA2
Power Indicator LED | rear face plate, lower left corner
Mesh Compatibility Compatible with all Starlink mesh systems *Not compatible with 3rd party mesh systems
Devices Connect up to 128 devices
